- General Information
- Manufacturer
- CyberPower Systems, Inc
- Manufacturer Website Address
- https://www.cyberpower.com/au
- Brand Name
- CyberPower
- Product Type
- PDU
The CyberPower PDU20BHVIEC12R, a 12-outlet (rear) rackmount basic power distribution unit (PDU), provides 208V/230V 20A output. It distributes power to 12 IEC-320 C13 receptacles from a single IEC-320 C20 plug with unfiltered electrical pass-through. Designed for datacenters and other electrically demanding applications, the PDU20BHVIEC12R has rugged, industrial-grade metal housing and a 10-foot AC power cord. It can be mounted either horizontally or vertically, includes a cord retention tray, and is ETL/RoHS certified. A limited lifetime warranty covers defects in materials and workmanship in the product under normal use and conditions.
- Technical Information
- PDU Type
- Basic
- Protection Type
- Overload Protection
- Power Description
- Input Voltage Range
- 200 V AC - 230 V AC
- Output Voltage
- 200 V AC
- 208 V AC
- 230 V AC
- Physical Characteristics
- Mounting Orientation
- Vertical
- Mount Type
- Rack-mountable
- Rack Height
- 1U
- Height
- 44.4 mm
- Width
- 444.5 mm
- Length
- 38.1 mm
- Weight (Approximate)
- 834.6 g
- Miscellaneous
- Additional Information
- Physical Dimensions - (WxHxD) (cm) : 44.45 x 4.45 x 3.81 (cm)
- Physical Dimensions - (WxHxD) (in) : 17.5 x 1.75 x 1.5 (in)
- Physical Dimensions - (WxHxD) (mm) : 445 x 44 x 38 (mm)
- Weight (kg) : 0.91
- Weight (lb) : 2
- Shipping Dimensions - (WxHxD) (cm) : 15.57 x 6.68 x 51.13 (cm)
- Shipping - Dimensions (WxHxD, in) : 6.13 x 2.63 x 20.13 (in)
- Shipping - Dimensions (WxHxD, mm) : 155.7 x 66.8 x 511.3 (mm)
- Shipping - Weight (kg) : 0.91
- Shipping - Weight (lb) : 2
- Cord Length : 10 ft (3.0 m)
- Input Frequency Range : 50 Hz - 60 Hz
- Input Plug Type : IEC-320 C20
- Maximum Input Current : 20A
- Nominal Output Voltage : 200 - 230 VAC
- Outlets - Front : 0
- Outlets - Rear : 12
- Outlets - Total : 12
- Outlet Type COMPUTED : 12 - IEC-320 C13
- Overload Protection : 16A
- USB Charge Port : No
- Adjustable Mounting Brackets : 2 sets (L-Short, L-Long)
- Color : Black
- Cord Retention Tray/Cord Organizers : Yes
- External Site Ground Pin : Yes
- Form Factors Supported : 1U Rackmount
- Material of Construction : Metal
- Rack Height : 1U
- Style : Rackmount
- Operating Elevation : 0 - 10000 ft (0 - 3048 m)
- Operating Relative Humidity : 0 - 95 % (non-condensing)
- Operating Temperature : 32 - 95 °F (0 - 35 °C)
- Storage Elevation : 0 - 50000 ft (0 - 15239 m)
- Storage Temperature : 5 - 113 °F (-15 - 45 °C)
- Environmental : RoHS Compliant
- Safety : UL60950_1 certified by ETL
- Product Warranty : Limited Lifetime Warranty
- Energy Star
- No
