- General Information
- Manufacturer
- CyberPower Systems, Inc
- Manufacturer Website Address
- https://www.cyberpower.com/au
- Brand Name
- CyberPower
- Product Type
- PDU
Streamline capacity planning and power management with the CyberPower PDU81004 switched metered-by-outlet PDU. Ideal for data centers and network closets, this unit provides outlet-level power monitoring in real time, along with individual outlet control for remote reboots, load shedding, controlled power-cycling and more.
The PDU81004 supports inputs between 100-240V and includes eight (8) IEC C13 outlets and a single IEC C14 input power plug. Other features include a rack mount design (1U), built-in web interface (RJ-45 ethernet connection), interactive digital display and power event notifications. The CyberPower PDU81004 is protected by a three-year limited warranty.
- Power Description
- Input Voltage Range
- 120 V AC - 230 V AC
- Input Current
- 15 A
- Management
- Management
- SNMP
- Interfaces/Ports
- Network (RJ-45)
- Yes
- Physical Characteristics
- Mount Type
- Rack-mountable
- Rack Height
- 1U
- Height
- 44.4 mm
- Width
- 433.1 mm
- Depth
- 112 mm
- Weight (Approximate)
- 2.10 kg
- Miscellaneous
- Additional Information
- Physical Dimensions - (WxHxD) (cm) : 43.31 x 4.45 x 11.2 (cm)
- Physical Dimensions - (WxHxD) (in) : 17.05 x 1.75 x 4.41 (in)
- Physical Dimensions - (WxHxD) (mm) : 433 x 44 x 112 (mm)
- Weight (kg) : 2.1
- Weight (lb) : 4.63
- Shipping Dimensions - (WxHxD) (cm) : 25.1 x 6.78 x 50.17 (cm)
- Shipping - Dimensions (WxHxD, in) : 9.88 x 2.67 x 19.75 (in)
- Shipping - Dimensions (WxHxD, mm) : 250.95 x 67.82 x 501.65 (mm)
- Shipping - Weight (kg) : 9.24
- Shipping - Weight (lb) : 20.38
- Cord Length : 10 ft (3.0 m)
- Derated Input Current : 12 A
- Input Frequency Range : 50 Hz - 60 Hz
- Input Plug Type : IEC-320 C14
- Maximum Input Current : 15A
- Nominal Input Voltage : 100 - 240 VAC
- Power Cord Length : 10 ft (3 m)
- Circuit Quantity : 1
- Nominal Output Voltage : 100 - 120 VAC
- Number of Outlets : 8
- Outlets - Total : 8
- Outlet Type COMPUTED : 8 - IEC-320 C13
- Overload Protection : None
- USB Charge Port : No
- Environmental Sensor : Optional, via RJ45
- Hardware Connection Port : RJ45
- LCD : Multifunction LCD
- Outlet switching : Yes
- Protocols : IPv4|TCP/IP|UDP|SNMPv1|HTTP|NTP|DNS|Telnet|DHCP|SMTP|FTP|IPv6|SNMPv3|HTTPs|SSH|SSL|TLS|LDAP(S)|RADIUS|Syslog|CLI|Windows AD
- Upgradeable firmware : Yes
- Color : Black
- Form Factors Supported : 1U Rackmount
- Material of Construction : Metal
- Rack Height : 1U
- Operating Elevation : 0 - 11483 ft (0 - 3500 m)
- Operating Relative Humidity : 0 - 95 % (non-condensing)
- Operating Temperature : 32 - 140 °F (0 - 60 °C)
- Storage Elevation : 0 - 49213 ft (0 - 14999 m)
- Storage Temperature : 5 - 149 °F (-15 - 65 °C)
- Safety : UL62368
- Extended Warranty Option : WEXT5YR-PDU1B
- Product Warranty : 3 Year Limited Warranty
